Single wall steel tubing
Shaanxi Yongrui Industry Co.,Ltd,We're leading manufacture of steel bundy tube . We has specialized in manufacturing steel tubes for automobiles and appliances for over 22 years.Our main product is Single wall welded steel tube.It's made by steel strip rolled 360°
Characteristics and features for single wall steel bundy tube
FEATURES
Economic
Lubricity of exterior surface
Retention of MAX 0.1948g/㎡ for internal cleanness
Durability for vibration, impact, and airtightness
Possibility for various processing
Possibility for galvanization and fluoroplastic coating
Chemical ingredient
C : MAX. 0.15%
Si : Trace
Mn : MAX. 0.60%
P : MAX. 0.050%
S : MAX. 0.050%
Mechanical property
Tensile Strength:≥290MPa
Yield Strength:≥180MPa
Elongation rate:≥14%
Flaring Test Flaring:≥25%
Allowable error
Exterior diameter : ±0.08mm
Thickness : ±0.08mm
Related official standard (including single winding steel tube)
GBT 24187-2009 | China Standards |
KS R 2028 | Korean Standards |
ASTM-A254 | American Society for Testing Materials |
SAE-J526 & J527 | Society of Automotive Engineers |
MS191-21 | HYUNDAI & KIA Motors Standards |
JASO M 101 | Japanese Automotive Standards |
GM123M, 124M | GM Standards |
GMW14658 | GM Global Standards |
Specifications
